Email: image options

The image feature carries what an email needs of an image, next to its file, alternative text and caption: a link, a width, and an overlay. They are fields of the inspector, so they are there in every appearance.

Text

Insert



Click the image to edit it.

Settings

Select a block to see its settings.

Fields

• size: "contained" takes theme.imageWidthRatio.contained of the width on the canvas (60% by default), centred: a logo, a portrait.
• overlay: "play" draws the play badge in the brand colour over the image. No email client plays an embedded video, so a video is a thumbnail that links to it.

The stored node

{
	"type": "image",
	"url": "https://cdn.example.com/thumbnail.jpg",
	"alt": "Our match against Lyon",
	"href": "https://example.com/video",
	"size": "contained",
	"overlay": "play",
	"children": [{ "text": "" }]
}

A node stored before these fields existed reads as href: "", size: "full", overlay: "none".

The web reader wraps the image in <a href> when there is a link, gives the figure style="width:60%;margin-inline:auto" when it is contained, and data-overlay="play" when it carries the badge.

From the email block editor

The old image block maps one to one, with two renames: its src is the node's url, and its width ("full", "contained") is the node's size, because width and height already hold the file's pixel size. alt, href and overlay keep their names and values.

Labels

fields.imageLink and fields.imageLinkDescription; fields.imageSize, fields.imageSizeFull, fields.imageSizeContained; fields.imageOverlay, fields.imageOverlayNone, fields.imageOverlayPlay and fields.imageOverlayPlayDescription.
